Image Processor

Spacial Manipulations

Resize Mode: Crop (default)

Resizes the original image to the given width and/or height.

Passing a single dimension will automatically preserve the aspect ratio of the original image. If the set dimensions do not match the aspect ratio of the original image then the output is cropped to match the new aspect ratio.

Images will be upscaled from the original if the requested size is larger than the original dimensions.

Crop mode also offers optional anchor positions which determine the origin point in which to resize the image from:

• center (default)
• top
• right
• bottom
• left
• topleft
• topright
• bottomleft
• bottomright

<img src="/your-image.jpg?width=[px]&height=[px]&mode=crop&anchor=[POSITION]">

<!--Automatic height based on width-->
<img src="/your-image.jpg?width=600">

<!--Automatic width based on height-->
<img src="/your-image.jpg?height=250">

<!--Both dimensions specified-->
<img src="/your-image.jpg?width=600&height=250">

<!--Both dimensions specified with the image anchored to the top-->
<img src="/your-image.jpg?width=600&height=250&anchor=top">

Since crop is the default resizing mode it does not need to be explicitly set in your query string.

Samples

Resize Mode: Pad

Resizes the original image to the given width and/or height and adding padding while upscaling the original if needed.

Passing a single dimension will automatically preserve the aspect ratio of the original image. If the requested aspect ratio is different then the original, then the image will be padded to fit.

Images will be upscaled from the original if the requested size is larger than the original dimensions.

Pad mode also offers optional anchor positions which determine the origin point in which to resize the image from:

• center (default)
• top
• right
• bottom
• left
• topleft
• topright
• bottomleft
• bottomright

You can also recolour the background color of the padded area (from the default black) for image types without transparency. Transparent image formats will use transparency in the padded area.

<img src="/your-image.jpg?width=[px]&height=[px]&mode=pad&anchor=[POSITION]&bgcolor=[COLOR]">

<!--Automatic height based on width-->
<img src="/your-image.jpg?width=600&mode=pad">

<!--Automatic width based on height-->
<img src="/your-image.jpg?height=250&mode=pad">

<!--Both dimensions specified-->
<img src="/your-image.jpg?width=600&height=250&mode=pad">

<!--Both dimensions specified with the image anchored to the top-->
<img src="/your-image.jpg?width=600&height=250&mode=pad&anchor=top">

<!--Background color added to padded image-->
<img src="/your-image.jpg?width=600&height=250&mode=pad&bgcolor=fff">

Samples

Resize Mode: BoxPad

Resizes the original image to the given width and/or height and adding padding without upscaling the original.

Passing a single dimension will automatically preserve the aspect ratio of the original image. If the requested aspect ratio is different then the original, then the image will be padded to fit.

Images will not be upscaled from the original if the requested size is larger than the original dimensions. While the requested dimensions are smaller than the original image, this method will behave the same as the Pad mode.

BoxPad mode also offers optional anchor positions which determine the origin point in which to resize the image from:

• center (default)
• top
• right
• bottom
• left
• topleft
• topright
• bottomleft
• bottomright

You can also recolour the background color of the padded area (from the default black) for image types without transparency. Transparent image formats will use transparency in the padded area.

<img src="/your-image.jpg?width=[px]&height=[px]&mode=boxpad&anchor=[POSITION]&bgcolor=[COLOR]">

<!--Automatic height based on width-->
<img src="/your-image.jpg?width=600&mode=boxpad">

<!--Automatic width based on height-->
<img src="/your-image.jpg?height=250&mode=boxpad">

<!--Both dimensions specified-->
<img src="/your-image.jpg?width=600&height=250&mode=boxpad">

<!--Both dimensions specified with the image anchored to the top-->
<img src="/your-image.jpg?width=600&height=250&mode=boxpad&anchor=top">

<!--Background color added to padded image-->
<img src="/your-image.jpg?width=600&height=250&mode=boxpad&bgcolor=fff">

Samples

Resize Mode: Min

Resizes the original image until the shortest side reaches the given width and/or height and no added padding without upscaling the original.

This will maintain the aspect ratio of the original image without upscaling. The original image will simply be returned if the requested dimensions exceed the original image.

<img src="/your-image.jpg?width=[px]&height=[px]&mode=min">

<!--Automatic height based on width-->
<img src="/your-image.jpg?width=600&mode=min">

<!--Automatic width based on height-->
<img src="/your-image.jpg?height=250&mode=min">

<!--Both dimensions specified-->
<img src="/your-image.jpg?width=600&height=250&mode=min">

Samples

Resize Mode: Max

Resizes the original image until the longest side reaches the maximum width and/or height and no added padding with upscaling the original.

This will maintain the aspect ratio of the original image and upscale where needed.

<img src="/your-image.jpg?width=[px]&height=[px]&mode=max">

<!--Automatic height based on width-->
<img src="/your-image.jpg?width=600&mode=max">

<!--Automatic width based on height-->
<img src="/your-image.jpg?height=250&mode=max">

<!--Both dimensions specified-->
<img src="/your-image.jpg?width=600&height=250&mode=max">

Samples

Resize Mode: Stretch

Resizes the original image to match the given width and height and no added padding with upscaling the original.

If the set dimensions do not match the aspect ratio of the original image then the output is stretched to match the new aspect ratio.

<img src="/your-image.jpg?width=[px]&height=[px]&mode=stretch">

<!--Automatic height based on width-->
<img src="/your-image.jpg?width=600&mode=stretch">

<!--Automatic width based on height-->
<img src="/your-image.jpg?height=250&mode=stretch">

<!--Both dimensions specified-->
<img src="/your-image.jpg?width=600&height=250&mode=stretch">

Samples

Rotate

Rotates the original image to a the given angle without clipping.

<img src="/your-image.jpg?rotate=[ANGLE]">

<!--Positive angle-->
<img src="/your-image.jpg?rotate=30">

<!--Negative angle-->
<img src="/your-image.jpg?rotate=-80">

<!--Angle with background color-->
<img src="/your-image.jpg?rotate=45&bgcolor=0091EA">

Samples

Crop

Crops the original image to the given location and size.

Location values are offsets given in x,y co-ordinates (from the top left) in pixels to start the cropping (based on the original image dimensions).

Size is given in width and height values in pixels to determine the size of the crop section (and resulting output image size).

If the total width (including any x offset) or total height (including any y offset) is larger then the original image, a broken image reference will be rendered.

<img src="/your-image.jpg?crop=[x],[y],[WIDTH],[HEIGHT]">

<img src="/your-image.jpg?crop=100,50,300,180">

Samples

Flip

Flips the original image either horizontal, vertical, or both.

<img src="/your-image.jpg?flip=[ORIENTATION]">

<!--Horizontal-->
<img src="/your-image.jpg?flip=horizontal">

<!--Vertical-->
<img src="/your-image.jpg?flip=vertical">

<!--Both-->
<img src="/your-image.jpg?flip=both">

Samples

Effects

BackgroundColor

Changes the color of padded space added to an output image when the image size/ratio does not fit the requested dimensions (when using one of the ImageProcessor resize methods).

This method typically applies to image formats that don't include an alpha (transparent) channel. However, it can also be used to set a background color in place of the transparency of processed images that do include an alpha channel.

<img src="/your-image.jpg?bgcolor=[COLOR]">

<!--Hex color-->
<img src="/your-image.jpg?bgcolor=800080">

<!--RGB color-->
<img src="/your-image.jpg?bgcolor=128,0,128">

<!--RGBA color-->
<img src="/your-image.jpg?bgcolor=128,0,128,255">

<!--HTML named color-->
<img src="/your-image.jpg?bgcolor=purple">

When using the RGBA color format, the alpha value is a range from 0 (transparent) to 255 (opaque). This color format only works for image formats that support alpha transparency channels.

Samples

Brightness

Adjusts the brightness of the original image based on a given percentage value. A positive value increases brightness while a negative value decreases brightness.

<img src="/your-image.jpg?brightness=[PERCENTAGE]">

<!--Increase brightness-->
<img src="/your-image.jpg?brightness=35">

<!--Decrease brightness-->
<img src="/your-image.jpg?brightness=-35">

Samples

Contrast

Adjusts the contrast of the original image based on a given percentage value. A positive value increases contrast while a negative value decreases contrast.

<img src="/your-image.jpg?contrast=[PERCENTAGE]">

<!--Increase contrast-->
<img src="/your-image.jpg?contrast=35">

<!--Decrease contrast-->
<img src="/your-image.jpg?contrast=-35">

Samples

Saturation

Adjusts the saturation of the original image based on a given percentage value. A positive value increases saturation while a negative value decreases saturation.

<img src="/your-image.jpg?saturation=[PERCENTAGE]">

<!--Increase saturation-->
<img src="/your-image.jpg?saturation=45">

<!--Decrease saturation-->
<img src="/your-image.jpg?saturation=-45">

Samples

Filter

Applies a pre-made filter type to the original image.

Available filter types are:

• blackwhite
• greyscale
• hisatch
• invert
• lomograph
• polaroid
• sepia

<img src="/your-image.jpg?filter=[TYPE]">

<img src="/your-image.jpg?filter=blackwhite">

Samples

GaussianBlur

Adjusts the blur of the original image based on a given Gaussian Blur kernal value. The kernal value can range anywhere from 1 to 10000.

<img src="/your-image.jpg?blur=[KERNAL]">

<img src="/your-image.jpg?blur=25">

Samples

Formats

Format

Converts the original image to the specified file type.

Supported file types are:

• jpg
• jpeg
• bmp
• gif
• png
• png8
• tif
• tiff

<img src="/your-image.jpg?format=[FILE TYPE]">

<!--GIF Format-->
<img src="/your-image.jpg?format=gif">

Samples

Quality

Resamples the original image to the specified percentage quality.

This method will only effect the output quality of images that allow lossy processing. So essentially JPG images - currently, WEBP images are not able to be processed with the ImageProcessor methods.

<img src="/your-image.jpg?quality=[PERCENTAGE]">

<!--25% Quality-->
<img src="/your-image.jpg?quality=25">

Samples
